Motivation

  • Show the 0.6mm reference-text result by refreshing the existing realistic PCB snapshot.

Before

  • The base snapshot renders the eight reference paths at 0.4mm.

After

  • The same snapshot renders the same board at 0.6mm.
  • 0.6mm reference text
