A from-scratch C inference engine for the hako model family. Own loader, own kernels, own tokenizer. hakm.

_{site  ·  releases  ·  models  ·  hako-code (agent)  ·  hako-edit (editor)  ·  hako-studio (browser)  ·  org}

--info · arch · params · GQA · ctx

--raw · greedy completion

one ChatML turn · honest tok/s split

From scratch. Own GGUF→MLF2 loader, own Q4_K/Q6_K + int8 kernels, own byte-level BPE, own Qwen2 forward pass. No ggml, no llama.cpp, no torch.

Three deps. libc + libm + pthread. That is the whole stack. make builds ./hakm on Linux / macOS / FreeBSD.

Resident + fast. --serve keeps the model warm and reuses the KV prefix across turns. Batched prefill, FMA q4k, a Q6_K int8 path, threaded attention, f16 KV — ~8 tok/s decode on a CPU-only i3.

_{—— I ——}

Overview

This repo is the engine. It runs the hako models end to end. hako-code (the agent) runs it as a hakm subprocess — a long-lived --serve process that keeps the model resident and reuses the KV cache — and hako-edit (the editor) reaches it through the agent. You can also run it directly.

• No ggml, no llama.cpp, no torch, no ollama. The loader, the k-quant + int8 kernels, the BPE tokenizer, and the Qwen2 forward pass are all hand-written C11. libc + libm + pthread is the entire runtime.
• Own container format — MLF2. tools/gguf2mlf.py converts a Qwen2.5-Coder GGUF to a native MLF2 file once (pure stdlib): k-quant blocks copied verbatim, tokenizer embedded, arch params in a fixed 128-byte header. The runtime mmaps it — RSS is just activations + KV cache.
• Runs the real weights. Qwen2.5-Coder 3B (hako-sho) and 7B (hako-koi) generate end to end — greedy + sampling, ChatML, multi-turn, tool-call dialect. Quant output is bit-exact vs an independent Python reimpl.
• CPU-only, and honest about it. This is correctness-first; the goal is owning the stack on old hardware, not beating tuned GPU runtimes. Speed wins come from int8 fast paths and KV reuse, measured on a 4-core i3-8100.

_{—— II ——}

Build & Run

curl -fsSL https://mithraeums.github.io/hakm.sh | sh    # release binary, or a source build where there is none (iSh)

git clone https://github.com/mithraeums/hako && cd hako
make                            # builds ./hakm — libc + libm + pthread, no deps
make test                       # the ASan gates (no weights needed)

Deps: libc + libm + pthread. No third-party libraries. Built -march=native by default; pass ARCH="" for a portable generic build, or ARCH="-arch arm64 -arch x86_64" for a macOS universal binary.

Get a model

Weights are never stored here — pull them from HuggingFace (huggingface.co/mithraeum) or convert your own:

hakm pull hako-sho      # resumable, checked, installed to ~/.hako/models/
hakm list               # what is installed
# (inside the agent: :pull hako-sho does the same)

# or convert a Qwen2.5-Coder GGUF yourself, once:
python3 tools/gguf2mlf.py model.gguf ~/.hako/models/hako-sho/hako-sho.mlf2

model	tier	base	license
hako-sho	mini · 3B	Qwen2.5-Coder-3B-Instruct	⚠️ Qwen-research (non-commercial)
hako-koi	mid · 7B	Qwen2.5-Coder-7B-Instruct	Apache-2.0

Future tiers (14B/32B fine-tune, 50B+ max) are queued. Stock wraps carry no version; the first real fine-tune of a tier earns v0.0.1.

Run

M=hako-sho                                            # an id, org/id, or a .mlf2 path

./hakm "$M" --info                                   # arch banner, then exit
./hakm "$M" --raw -t 0 "def fibonacci(n):"           # raw greedy completion
./hakm "$M" --sys "You are hako." "ring buffers in C" # one ChatML turn
./hakm "$M" --sys "You are hako."                    # interactive multi-turn REPL
./hakm --version

Flags: -n new-tokens · -t temp (0 = greedy) · -p top_p · -k top_k · --rep F repetition penalty (1 = off) · --rep-window N (default 64) · -s seed · --sys TEXT · --ctx N · --raw · --info · --chat-stdin · --serve · --no-kv-cache. hakm --help lists them, plus the environment knobs.

_{—— III ——}

How it works

1. Offline conversion — tools/gguf2mlf.py reads a GGUF and emits an MLF2 file: the native container. Quant blocks are copied verbatim (ggml's k-quant layout preserved), tokenizer (vocab + merges) embedded, arch params in a fixed 128-byte header. Pure stdlib — no torch / llama.cpp dependency.

2. Runtime (C11, libc + libm + pthread):

   • loader.c — mmap the MLF2, resolve tensors by name. RSS = activations + KV.
   • quant.c — Q4_K / Q6_K dequant + int8 fast-path dot (quantize the activation to int8 once, dot straight against the k-quant weights; weights stay exact). Bit-exact vs tests/q_ref.py. AVX2-FMA + scalar paths.
   • nn.c — rmsnorm, softmax, SiLU, NeoX rope, int8 matmul, and a generic hakm_parallel worker pool (matmul rows + attention heads share it).
   • model.c — Qwen2 forward: GQA, QKV bias, KV cache (f16 when __F16C__), batched prefill, threaded attention, lm_head (tied on 3B, output.weight on 7B+).
   • bpe.c — Qwen2 byte-level BPE (GPT2 byte map + rank-greedy merges).
   • cli/main.c — the hakm CLI: one-shot, --raw, chat REPL, --chat-stdin, and the resident --serve loop.

3. Serve loop — --serve is a resident framed-request loop. Each request's rendered conversation is prefix-matched against the KV-cached tokens; rollback is just pos = p; only the unseen tail prefills. This is how the agent gets warm turns in seconds instead of re-prefilling the whole system prompt every turn. Optional per-request temperature (greedy on tool turns) and token cap.

_{—— IV ——}

Validated

Runs the real Qwen2.5-Coder 3B and 7B weights end to end (greedy + sampling, ChatML, multi-turn REPL, --serve):

• 3B (hako-sho): qwen2 · 36 layers · d_model 2048 · 16/2 heads (GQA) · ffn 11008 · vocab 151936 · tied embeddings.
• 7B (hako-koi): qwen2 · 28 layers · d_model 3584 · 28/4 heads (GQA) · ffn 18944 · vocab 152064 · untied (output.weight).

Quant correctness gate: C output bit-exact vs tests/q_ref.py (Q4_K + Q6_K, maxdiff 0.0). Strict-FP build is batch-vs-single bit-identical. ASan + UBSan clean on chat + serve paths.

make test                          # attention bounds, KV cache, Q8_0, damaged model files (ASan)
make test_quant                    # build/test_quant: dequant a real tensor for tests/q_ref.py
make test_kdot                     # build/test_kdot: fused Q4_K dot vs scalar, on real weights

_{—— V ——}

Speed

CPU-only, measured on a 4-core i3-8100 (the staging box itself):

• Decode ~8 tok/s, flat with depth (was 2.35 → ~3.4×), via the Q6_K int8 dot path, threaded attention, and an f16 KV cache that stops decode sagging as context grows.
• Batched prefill ~4.7× — matmul_batch streams each weight row from RAM once per batch (hot in L1 for the other B−1 dots); the FMA q4k kernel keeps 8-lane int32 partials vectorized with one hsum per row.
• Prefill ~1.3× on top of that (compute-bound once weight streaming is amortized) — the q4k min term (dmin·m·Σx) is activation-only, so scale·Σx is folded once per activation and reused across every weight row, freeing half the per-group port-0 MACs. Greedy output stays bit-identical.
• Warm agent turns ~3–5s (were 5+ minutes) — --serve keeps the model resident and reuses the KV prefix, so only the new tail prefills.
• 7B (hako-koi) is viable on 8GB — ~4 tok/s decode, RSS ~4.4GB.

Honest framing: the int8 paths keep weights exact (greedy output is bit-identical to the float path), and the tok/s print splits prefill from decode rather than blending them. Decode is near the box's bandwidth/compute floor; the next jumps are speculative decode (needs a draft model) or a register-blocked prefill GEMM micro-kernel (amortize the weight nibble-unpack across batch columns) — not more threads.

_{—— VI ——}

Change Log

Latest — engine v0.0.4

• Local answers stream — --serve sends each token as it is sampled (T <len> frames; opt-in via a 4th header field, so old callers and old engines are unaffected). The agent types a local reply out in real time.
• KV prefix on disk — the prefilled system prompt is saved under ~/.hako/cache/kv/ and restored on the next run: cold first turn on the i3 went from 255 s to 2.3 s. Keyed on model size+mtime, layers, kv dim, kv type and the exact token ids; --no-kv-cache opts out.
• …and the cache is bounded — one file per distinct system prompt, and nothing ever deleted them (359 MB piled up before anyone looked). Oldest first to HAKM_KV_DIR_MAX_MB (default 1024; 0 disables), the just-written entry exempt.
• Small models no longer overflow — att_heads indexed its scores by position but two call sites passed a buffer sized by ffn_dim; safe for sho/koi, a heap overflow for anything smaller. make test_attn reproduces it under ASan if undone.
• 32-bit / iSh — builds on musl (-D_DEFAULT_SOURCE, posix_madvise); no -march=native on i386, where the emulator advertises AVX/FMA it cannot run (that was SIGILL mid-prefill); prefault off; a model larger than the address space is refused with a message instead of a SIGBUS.
• Model store — hakm list | pull | rm, resumable pulls, atomic install; llama arch (SmolLM2 proven) and Q8_0 (make test_q8).
• Damaged files are refused — a truncated download or a corrupt tokenizer gets a message (model file is incomplete … run hakm pull again) instead of a segfault; make test builds damaged files and checks each one.

Earlier versions, and the full detail: CHANGELOG.md.

_{—— VII ——}

Known gaps / next

• Windows: the loader uses POSIX mmap; MinGW lacks sys/mman.h. An #ifdef _WIN32 mmap shim is the unlock. Linux (glibc and musl, 64- and 32-bit), macOS and FreeBSD build today.
• Tokenizer pretokenizer is simplified (whitespace-delimited; merges, symbols, special tokens correct). Needs the full Qwen2 regex for digit/punctuation-run boundaries to exactly match reference tokenization.
• Decode ceiling: near the i3's bandwidth/compute floor. Real breaks = speculative decode (sho as a draft model for koi — needs the training lane) or a smaller quant tier.
• Prefill: a q4k/q6k GEMM micro-kernel (hoist nibble-unpack across the batch) is the next pure-engine lever; NEON q6k path for arm64.

Roadmap

• MLF2 loader + own k-quant dequant (bit-exact)
• Qwen2 GQA forward, NeoX rope, byte-level BPE
• int8-activation × int4-weight fast dot (AVX2-FMA + scalar)
• --serve resident loop + KV prefix reuse
• batched prefill, Q6_K int8 path, threaded attention, f16 KV
• runs 3B (hako-sho) + 7B (hako-koi) end to end
• token streaming in --serve; the prefilled system prompt kept on disk, bounded by eviction
• hakm list | pull | rm; llama-architecture models; Q8_0
• builds and tests on glibc, musl and 32-bit i386 (the iSh userland)
• Windows mmap shim
• full Qwen2 pretokenizer regex
• NEON q6k path (arm64) + prefill GEMM micro-kernel
• speculative decode (draft model from the training lane)

_{—— VIII ——}

Source layout

src/loader.c       mmap MLF2, resolve tensors, refuse damaged files
src/quant.c        Q4_K / Q6_K / Q8_0 dequant + int8 fast dot (bit-exact)
src/nn.c           rmsnorm, softmax, SiLU, rope, matmul, worker pool
src/model.c        Qwen2 / llama forward — GQA, KV cache, batched prefill, threaded attn
src/bpe.c          byte-level BPE (encode + decode)
src/sample.c       temp / top-k / top-p / greedy, repetition penalty
src/kvcache.c      the system-prompt KV prefix on disk, with eviction
src/models.c       hakm list / pull / rm — the model store
src/hakm_api.c     optional in-process library (libhakm.a); not the agent's path
cli/main.c         the hakm CLI — one-shot / raw / REPL / --chat-stdin / --serve
include/mlf2.h     the native container format
tools/gguf2mlf.py  offline GGUF → MLF2 converter (pure stdlib)
tests/             make test (ASan) + the real-weights checks and q_ref.py
install.sh         the installer behind mithraeums.github.io/hakm.sh

Contributing

If you share the belief that simplicity empowers creativity, feel free to contribute.

Contribution is welcome in the form of:

• Forking this repo
• Submitting a Pull Request
• Bug reports and feature requests

Please ensure your code follows the existing style — C11, tabs, snake_case, ASan + UBSan clean, quant changes proven bit-exact against tests/q_ref.py.

License

• Engine code — GPL-3.0 (LICENSE). From-scratch C; no ggml/llama.cpp/torch.
• Model weights keep their required upstream licenses (on HuggingFace, not here): hako-koi (7B) Apache-2.0; hako-sho (3B) Qwen RESEARCH — non-commercial only (the 3B base is research-licensed). See each model repo's LICENSE / NOTICE.

_{— SEE LICENSE —  ·  GPL-3.0}
