blastrad

CI/CD Pipeline Attack Path Analyzer for GitLab

blastrad models your GitLab CI/CD pipeline as a directed security graph and finds attack paths from untrusted sources to critical targets. It answers the question: "If someone opens a fork merge request, what secrets and environments can they reach?"

[CRITICAL] Privilege escalation: merge_request_event → deploy-production → K8S_TOKEN
──────────────────────────────────────────────────────────────────────────────────────
  Path:         merge_request_event → deploy-production → K8S_TOKEN
  Blast Radius: 3 critical resource(s)
  Description:  Untrusted source 'merge_request_event' can reach critical resource
                'K8S_TOKEN' (secret) in 2 step(s). An attacker can exploit this
                path to perform unauthorized actions.

[HIGH] Production job running on shared runner
──────────────────────────────────────────────────────────────────────────────────────
  Path:         deploy-production → shared-runner-01
  Blast Radius: 1 critical resource(s)
  Description:  Job 'deploy-production' deploys to production but uses shared
                runner 'shared-runner-01'. Jobs from other projects using this
                runner can access this job's temp files and cache.

---

Why blastrad?

Most CI/CD security tools are rule-based: they flag a pattern and say "this is bad" — but they don't tell you why it's bad, what an attacker can actually reach, or how many hops it takes.

Tool	What it does	What's missing
Checkov	YAML rule checks	No context, no relationship analysis
gitleaks	Secret scanning	Only secrets, no reachability analysis
zizmor	GitHub Actions linter	GitHub only, no GitLab support
Semgrep	Pattern matching	Not pipeline-specific
blastrad	Graph-based attack path analysis	—

blastrad's differentiator: it shows concretely how many steps a fork MR attacker needs to reach K8S_TOKEN, which jobs they traverse, and how much damage they can do from there.

---

How it works

Pipeline analysis happens in three phases:

1. Data collection

.gitlab-ci.yml is parsed to extract job definitions, trigger conditions, dependencies, and environment configuration. The GitLab API is then queried to fill in protected/masked state for variables, environment protection settings, and runner configuration.

2. Graph modeling

The collected data is converted into a directed graph:

Node types:  Trigger | Job | Secret | Environment | Runner
Edge types:  triggers | reads_secret | deploys_to | runs_on | depends_on

Example:
  [fork_mr] ──triggers──▶ [deploy-prod] ──reads_secret──▶ [K8S_TOKEN]
                                 │
                           ──deploys_to──▶ [production]
                                 │
                           ──runs_on──▶ [shared-runner-01]

3. Analysis

Two analyses run over the graph:

• Privilege escalation path finding: DFS starts from every untrusted trigger node. Any path that reaches a critical target (a protected=false secret or an unprotected production environment) is reported as a finding.
• Blast radius calculation: For each finding, the number of critical resources reachable from the target node is calculated.

---

Installation

git clone https://github.com/karakoc49/blastrad
cd blastrad
go build -o blastrad .

Requires Go 1.22+.

---

Usage

Create a GitLab token

GitLab → Settings → Access Tokens → create a token with the read_api scope.

Basic usage

blastrad scan --token glpat-xxxx --project mygroup/myproject

Self-hosted GitLab

blastrad scan \
  --token glpat-xxxx \
  --project 42 \
  --url https://gitlab.example.com

Non-default CI file path

blastrad scan \
  --token glpat-xxxx \
  --project mygroup/myproject \
  --file ci/production.yml

All flags

Flag	Short	Default	Description
--token	-t	—	GitLab Personal Access Token (read_api scope) [required]
--project	-p	—	Project ID or namespace/project path [required]
--url	-u	https://gitlab.com	GitLab instance URL
--file	-f	.gitlab-ci.yml	Path to the CI/CD file

CI/CD integration

blastrad exits with code 1 when CRITICAL or HIGH findings are present, making it easy to gate pipelines:

# .gitlab-ci.yml
security-scan:
  stage: security
  image: golang:1.22
  script:
    - go install github.com/karakoc49/blastrad@latest
    - blastrad scan --token $BLASTRAD_TOKEN --project $CI_PROJECT_PATH
  allow_failure: false  # Pipeline stops if critical findings are found

---

Findings

Privilege escalation path

A path from an untrusted source (anyone who can open a fork MR) to a critical target.

Example scenario:

deploy-prod:
  environment: production
  variables:
    K8S_TOKEN: $KUBE_SECRET   # protected=false in GitLab
  rules:
    - if: '$CI_MERGE_REQUEST_IID'  # fork MRs can trigger this

blastrad detects that anyone who opens a fork can trigger deploy-prod, and deploy-prod can access K8S_TOKEN.

Severity: CRITICAL or HIGH depending on the variable's protected/masked state.

Production job on shared runner

A job that deploys to a production environment runs on a runner shared with other projects.

Risk: Jobs from other projects running on the same shared runner can access temp files, cache, and in some cases environment variables left behind.

Severity: HIGH

---

What to fix

Finding	Fix
Unprotected secret reachable from fork MR	Set protected=true on the variable in GitLab → Settings → CI/CD → Variables, or add a rule to exclude MR pipelines from the deploying job
Production job on shared runner	Use a project-specific runner tagged for production jobs
Unprotected production environment	Enable environment protection in GitLab → Settings → CI/CD → Protected environments

---

Architecture

blastrad/
├── main.go
├── cmd/
│   ├── root.go          # cobra root command
│   └── scan.go          # "blastrad scan" subcommand and flag definitions
├── collector/
│   ├── parser/
│   │   ├── types.go     # Pipeline, Job, Rule, Environment structs
│   │   └── parser.go    # Two-phase YAML parsing logic
│   └── gitlab/
│       ├── types.go     # GitLab API response structs
│       ├── client.go    # HTTP layer with automatic pagination
│       └── fetcher.go   # Fetches variables, environments, runners
├── graph/
│   ├── node.go          # Node/Edge types, trust and criticality model
│   ├── graph.go         # Adjacency list graph implementation
│   ├── builder.go       # Converts parser + API data into a graph
│   └── analyzer.go      # DFS path finding, blast radius calculation
└── reporter/
    └── terminal.go      # Colored terminal output, deduplication

---

Development

# Run all tests
go test ./...

# Run a specific package with verbose output
go test ./graph/... -v

# Build
go build -o blastrad .

Adding a new rule

To add a new security rule, write a find* function in graph/analyzer.go and call it from Analyze():

func (a *Analyzer) Analyze() []Finding {
    var findings []Finding
    findings = append(findings, a.findPrivEscPaths()...)
    findings = append(findings, a.findSharedRunnerRisks()...)
    findings = append(findings, a.findMyNewRule()...)  // ← add here
    return findings
}

---

Roadmap

• SARIF output (GitLab/GitHub Security Dashboard integration)
• GitHub Actions support
• JSON output format
• --only-critical flag for filtered output
• Cross-pipeline dependency analysis (needs: pipeline:)
• Follow include: directives to external CI files

---

Required token scopes

Scope	Reason
read_api	Read project variables, environments, and runners

Both Personal Access Tokens and Project Access Tokens work.

---

Limitations

• Reads the CI file from disk, not from the GitLab API (use --file for non-default paths)
• Does not follow include: directives to external files
• Cross-project pipeline dependencies (needs: pipeline:) are not traversed
• Dynamic child pipelines (trigger:) are not analyzed

---

License

This project is distributed under the AGPL-3.0 license.

For commercial use or private licensing: haluk.mkarakoc@gmail.com

---

blastrad is an independent security tool written in Go and is not affiliated with GitLab Inc.
