在快速集成中，我们使用官方推荐的Electron Forge创建程序。可以用来开发react但是需要很多配置，我们在这个例子中换一个更简单的脚手架： create-electron

1.创建项目

npm create @quick-start/electron
> npx
> "create-electron"

✔ Project name: … electron-app-react
✔ Select a framework: › react
✔ Add TypeScript? … No / Yes
✔ Add Electron updater plugin? … No / Yes
✔ Enable Electron download mirror proxy? … No / Yes

Scaffolding project in electron-app-react...

Done. Now run:

cd electron-app-react
npm install
npm run dev

编辑器打开项目，可以看到目录结构如下

2.安装扩展

执行命令

npm i nodeplayer-addon

3.编辑 src/main/index.js 文件

import { app, shell, BrowserWindow, ipcMain } from 'electron'
import { join } from 'path'
import { electronApp, optimizer, is } from '@electron-toolkit/utils'
import icon from '../../resources/icon.png?asset'
import NodePlayerAddon from 'nodeplayer-addon'

function createWindow() {
  // Create the browser window.
  const mainWindow = new BrowserWindow({
    width: 900,
    height: 670,
    show: false,
    autoHideMenuBar: true,
    ...(process.platform === 'linux' ? { icon } : {}),
    webPreferences: {
      preload: join(__dirname, '../preload/index.js'),
      sandbox: false
    }
  })

  mainWindow.on('ready-to-show', () => {
    mainWindow.maximize();
    mainWindow.show()
  })

  mainWindow.webContents.setWindowOpenHandler((details) => {
    shell.openExternal(details.url)
    return { action: 'deny' }
  })

  // HMR for renderer base on electron-vite cli.
  // Load the remote URL for development or the local html file for production.
  if (is.dev && process.env['ELECTRON_RENDERER_URL']) {
    mainWindow.loadURL(process.env['ELECTRON_RENDERER_URL'])
  } else {
    mainWindow.loadFile(join(__dirname, '../renderer/index.html'))
  }

   mainWindow.on('closed', () => {
    NodePlayerAddon.unregisterIpc(ipcMain)
  })
  NodePlayerAddon.registerIpc(ipcMain, {
    getWindow: () => mainWindow,
    licensePath: app.isPackaged
      ? join(process.resourcesPath, 'license.dat')
      : join(__dirname, 'license.dat'),
  })
}

// This method will be called when Electron has finished
// initialization and is ready to create browser windows.
// Some APIs can only be used after this event occurs.
app.whenReady().then(() => {
  // Set app user model id for windows
  electronApp.setAppUserModelId('com.electron')

  // Default open or close DevTools by F12 in development
  // and ignore CommandOrControl + R in production.
  // see https://github.com/alex8088/electron-toolkit/tree/master/packages/utils
  app.on('browser-window-created', (_, window) => {
    optimizer.watchWindowShortcuts(window)
  })

  // IPC test
  ipcMain.on('ping', () => console.log('pong'))

  createWindow()

  app.on('activate', function () {
    // On macOS it's common to re-create a window in the app when the
    // dock icon is clicked and there are no other windows open.
    if (BrowserWindow.getAllWindows().length === 0) createWindow()
  })
})

// Quit when all windows are closed, except on macOS. There, it's common
// for applications and their menu bar to stay active until the user quits
// explicitly with Cmd + Q.
app.on('window-all-closed', () => {
  if (process.platform !== 'darwin') {
    app.quit()
  }
})

// In this file you can include the rest of your app's specific main process
// code. You can also put them in separate files and require them here.

4. 编辑src/preload/index.js

import { contextBridge, ipcRenderer } from 'electron'

contextBridge.exposeInMainWorld('electronAPI', {
  createPlayer: (id) => ipcRenderer.invoke('player:create', id),
  startPlayer: (id, url) => ipcRenderer.invoke('player:start', id, url),
  stopPlayer: (id) => ipcRenderer.invoke('player:stop', id),
  destroyPlayer: (id) => ipcRenderer.invoke('player:destroy', id),
  startRecord: (id, filePath) => ipcRenderer.invoke('player:startRecord', id, filePath),
  stopRecord: (id) => ipcRenderer.invoke('player:stopRecord', id),
  // 截图：将渲染进程生成的 JPG base64 数据保存到指定路径（默认由主进程自动生成）
  saveScreenshot: (id, outputPath, base64Data) => ipcRenderer.invoke('player:saveScreenshot', id, outputPath, base64Data),
  // 预探测：在创建播放器前分析 URL（连接性 / 编码 / 分辨率 / 首帧截图）
  getMediaInfo: (url) => ipcRenderer.invoke('player:getMediaInfo', url),

  onEvent: (id, callback) => {
    const channel = `player:event:${id}`
    const handler = (event, data) => callback(data)
    ipcRenderer.on(channel, handler)
    return () => ipcRenderer.removeListener(channel, handler)
  },

  onInfo: (id, callback) => {
    const channel = `player:info:${id}`
    const handler = (event, info) => callback(info)
    ipcRenderer.on(channel, handler)
    return () => ipcRenderer.removeListener(channel, handler)
  },

  onData: (id, callback) => {
    const channel = `player:data:${id}`
    const handler = (event, data) => callback(data)
    ipcRenderer.on(channel, handler)
    return () => ipcRenderer.removeListener(channel, handler)
  }
})

5.编辑src/renderer/src/App.jsx

import { useRef, useEffect, useState, useCallback } from 'react'
import NodePlayerView from 'nodeplayer-addon/NodePlayerView'

function App() {
  const videoRef = useRef(null)
  const playerRef = useRef(null)
  const [url, setUrl] = useState('')
  const [status, setStatus] = useState('')
  const [recording, setRecording] = useState(false)

  useEffect(() => {
    const player = new NodePlayerView(videoRef.current, `player-${Date.now()}`)
    player.on('event', (code, msg) => {
      if (code === 3001) setRecording(true)
      if (code === 3002 || code === 3003) setRecording(false)
    })
    player.on('error', (err) => { setStatus(err.message) })
    playerRef.current = player

    return () => {
      player.stop()
    }
  }, [])

  const handleStart = useCallback(() => {
    playerRef.current?.start(url)
  }, [url])

  const handleStop = useCallback(() => {
    playerRef.current?.stop()
  }, [])

  const handleRecord = useCallback(() => {
    const p = playerRef.current
    if (!p) return
    p.isRecording ? p.stopRecord() : p.startRecord()
  }, [])

  const handleScreenshot = useCallback(async () => {
    const p = playerRef.current
    if (!p) return
    const r = await p.saveScreenshot()
    setStatus(r.success ? '截图已保存：' + r.path : (r.error || '截图失败'))
  }, [])

  return (
    <div style={{ maxWidth: 800, margin: '10px', fontFamily: 'sans-serif' }}>
      <div style={{ position: 'relative', width: '100%', aspectRatio: '16 / 9', background: '#000' }}>
        <video
          ref={videoRef}
          autoPlay
          muted
          playsInline
          style={{ width: '100%', height: '100%', display: 'block', objectFit: 'contain' }}
        />
        {status && (
          <div
            style={{
              position: 'absolute',
              top: 8,
              left: 8,
              color: '#0f0',
              fontFamily: 'monospace',
              fontSize: 12
            }}
          >
            {status}
          </div>
        )}
      </div>
      <div style={{ display: 'flex', gap: 8, padding: '10px 0' }}>
        <input
          type="text"
          value={url}
          onChange={(e) => setUrl(e.target.value)}
          placeholder="rtsp:// 或 http://"
          style={{ flex: 1, padding: '6px 10px', fontSize: 14 }}
        />
        <button onClick={handleStart}>播放</button>
        <button onClick={handleStop}>停止</button>
        <button onClick={handleRecord}>{recording ? '停止录像' : '录像'}</button>
        <button onClick={handleScreenshot}>截图</button>
      </div>
    </div>
  )
}

export default App

运行效果

加上样式后的运行效果

6. 更多功能

上面的示例只演示了「播放 / 停止 / 录像 / 截图」。registerIpc 实际在主进程注册了更多能力，下面按需选用。

事件码参考

播放器通过 player.on('event', (code, msg) => {}) 推送事件，常用码如下：

范围 code 含义
连接 1000 正在连接
1001 已连接
1002 连接失败
1003 重连中
1004 已断开
1005 网络错误
1006 连接超时
录像 3001 录像开始
3002 录像停止
3003 录像错误

流的编码、分辨率、采样率等参数通过 player.on('info', (info) => {}) 单独推送，不走 event。

流预探测（getMediaInfo）

在加入播放列表前，可先探测地址是否可达、获取音视频参数并截取首帧预览图。

👉 完整 API、codec 参考表与示例：get-media-info.md

截图

NodePlayerView 提供两种截图方式，均在流就绪后调用：

  • player.saveScreenshot(outputPath?, quality?) → 通过 IPC 将 JPG 写入磁盘，返回 { success, path }，路径省略时由主进程自动生成
// 直接预览（不落盘）
const dataUrl = player.captureScreenshot(0.9)
if (dataUrl) snapshotImg.src = dataUrl

// 保存到文件
const r = await player.saveScreenshot()
if (r.success) console.log('已保存：', r.path)

联系客服索取demo源码
